| Specification |
| Type | Desktop Sheet-Fed Scanner |
| Scanning Speed*1 | |
| Greyscale | 200 dpi: 15 ppm (Simplex) / 30 ipm (Duplex) |
| 300 dpi: 15 ppm (Simplex) / 30 ipm (Duplex) |
| Colour | 200 dpi: 10 ppm (Simplex) / 20 ipm (Duplex) |
| 300 dpi: 6 ppm (Simplex) / 12 ipm (Duplex) |
| Scanning Element | Contact Image Sensor (CIS) |
| Light Source | LED |
| Scanning Side | Simplex / Duplex |
| Scanning Modes | Black and White, Error Diffusion, Advanced Text Enhancement II, 256-level Greyscale, 24-bit Colour |
| Scanner Features | Double-Feed Detection, Moiré Reduction, MultiStream |
| Output Resolution*2 | 150, 200, 300, 400, 600 dpi |
| Suggested Daily Volume (SDV) | 500 scans a day |
| Media Handling | |
| Document Size | |
| Plain Paper | Width: 50.8 to 216 mm |
| Length: 70 to 356 mm |
| (Up to 1,000 mm long with Long Document mode) |
| Business Card | Width: 49 to 55 mm |
| Length: 85 to 91 mm |
| Card (ISO Standard) | 86 x 54 mm |
| Document Thickness and Weight | |
| Plain Paper | 52 to 128 g/m² (0.06 to 0.15 mm) |
| Business Card | 128 to 225 g/m² (0.15 to 0.3 mm) |
| Card | 0.76 mm or smaller |
| (Up to 1.4 mm for embossed cards) |
| Auto Document Feeder (ADF) Capacity*3 | 20 sheets |
| Connectivity & Software | |
| Interface | USB 3.0 / 2.0 |
| Software | ISIS / TWAIN Drivers, CaptureOnTouch Lite, CaptureOnTouch |
| General | |
| Power Requirements | USB 2.0: 0.5 A (Communication cable only) / 1 A (In combination with power supply USB cable) |
| USB 3.0: 0.9 A / 6 V DC, 0.8 A (With optional AC adapter) |
| Power Consumption | |
| Scanning (Max.) | USB cable only: 2.5 W (USB 2.0) / 4.5 W (USB 3.0) |
| USB cable and power supply USB cable: 5 W (USB 2.0) / 7 W (USB 3.0) |
| Sleep Mode | 1.5 W |
| With Power Switched OFF (Max.) | 0.1 W |
| Operating Environment | |
| Temperature | 10 to 32.5°C |
| Humidity | 25 to 80% RH |
| Dimensions (W x D x H) | |
| When Trays Are Closed | 285 x 95 x 40 mm |
| When Trays Are Opened | 285 x 257 x 174 mm |
| Weight (Approx.) | 1 kg |
