| Specification |
| Printer | |
Printer Type | 5-Colour 36" (914 mm) |
| Number of Nozzles | 15,360 nozzles |
| (MBK 5,120 nozzles, |
| Other Colours 2,560 nozzles each) |
| Maximum Print Resolution | 2,400 x 1,200 dpi |
| Nozzle Pitch | 1,200 dpi (2 lines) |
| Line Accuracy*1 | ± 0.1% or less |
| Ink Capacity | Sales Ink: 130 ml/300 ml (MBK/BK/C/M/Y) |
| Ink Type | Pigment Ink |
| Printer Language | SG Raster (Swift Graphic Raster) |
| HP-GL/2, HP RTL |
| JPEG (Ver. JFIF1.02) |
| CALS G4*2 |
| Printing Solutions | Printer Driver (Win/Mac versions), Direct Print Plus, Free Layout plus, PosterArtist Windows/Web & Lite, Wi-Fi Connection Assistant, PIXMA Cloud Link, Apple AirPrint (Mobile), Canon PRINT Inkjet/SELPHY (Mobile), Canon Print System (Mobile), uniFlow server |
| Management Solutions | Media Configuration Tool (includes Colour Customization Tool), Accounting Manager, Device Management Console, Quick Utility Toolbox |
| Standard Interfaces (Built-in) | USB B Port: |
| (Series B, 4 pins) |
| Hi-Speed USB |
| Full Speed (12 Mbit/sec) |
| High Speed (480 Mbit/sec) |
| Bulk Transfer |
| Network: |
| IEEE 802.3 10base-T |
| IEEE 802.3u 100base-TX |
| IEEE 802.3ab 1000base-T |
| SNMP, HTTP, TCP/IP (IPv4/IPv6), FTP |
| Wireless LAN: |
| IEEE802.11 b/g/n |
| WPA-PSK (TKIP/AES) |
| WPA2-PSK (TKIP/AES) |
| WPA3-SAE (AES) |
| WPA-EAP (AES)*3 |
| WPA2-EAP (AES)*3 |
| WPA3-EAP (AES)*3 |
| Standard Memory | 2 GB |
| Hard Disk | - |
| Display | LCD (4.3 inch/10.9 cm TFT colour) |
| Print Speed*4 | |
| Media Handling | |
Media Feed and Output | |
| Roll Paper | One Roll, Top Load, Front Output |
| Cut Sheet | Top Load, Front Output |
| Media Width (Roll/Cut Sheet) | Roll Width: 203.2 ~ 917 mm; |
| Cut Sheet Width: 203.2 ~ 917 mm |
| Media Thickness (Roll/Cut Sheet) | 0.07 ~ 0.8 mm |
| Media Core Size | 2 inch/3 inch core |
| Min. Printable Length | |
| Roll Paper | 203.2 mm |
| Cut Sheet | 279.4 mm |
| Max. Printable Length | |
| Roll Paper | 18 m*5 |
| Cut Sheet | 1,600 mm |
| Maximum Outer Roll Diameter | 150 mm or less |
| Borderless Printing | Supported for roll paper |
| Margins (Recommended Area) | |
| Roll Paper (Top, Bottom, Sides) | 20 mm, 3 mm, 3 mm |
| Cut Sheet (Top, Bottom, Sides) | 20 mm, 20 mm, 3 mm |
| Margins (Printable Area) | |
| Roll Paper (Top, Bottom, Sides) | 3 mm, 3 mm, 3 mm |
| Cut Sheet (Top, Bottom, Sides) | 3 mm, 20 mm, 3 mm |
| Dimensions & Weight | |
Dimensions (W x D x H) | |
| Main Unit | 1,285 x 748 x 439 mm (Operation panel is not tilt up) |
| Main Unit + Printer Stand + Basket (SD-35) | 1,285 x 885 x 1,060 mm (Operation panel is not tilt up/Basket Opened） |
| 1,285 x 756 x 1,060 mm (Operation panel is not tilt up/Basket Closed) |
| Weight *6 | |
| Main Unit | 50 kg |
| Main Unit + Printer Stand + Basket (SD-35) | 65 kg |
| Packaged Dimensions (W x D x H) | |
| Printer (Main unit + Stand + Basket + Pallet) (SD-35) | 1,462 x 1,122 x 801 mm |
| Packaged Weight *6 | |
| Printer (Main unit + Stand + Basket + Pallet) (SD-35) | 113 kg |
| Power & Operating Requirements | |
Power Supply | AC 100 - 240 V, 50 - 60 Hz |
| Power Consumption | |
| Printing*7 | 65 W or less |
| Sleep Mode*7 | 1.6 W or less |
| Power Off | 0.1 W or less |
| Operating Environment | |
| Temperature | 15 ～ 30 °C |
| Humidity | 10 ～ 80 % RH (no dew condensation) |
| Acoustic Sound | |
| Acoustic Power*8 | Operation: Approx. 6.2 Bels |
| Acoustic Pressure*8 | Operation: Approx. 41 dB (A) |
| Standby: 35 dB (A) or less |
| Accessories | |
Printer Stand (Optional) | - |
| 2/3" Roll Holder | RH2-35 |
| Card Reader Interface for uniFLOW | RA-02 |
| Cutter Blade | CT-08 |
| Consumables | |
Ink Tank | Magenta: PFI-8121 (130 ml)/PFI-8321 (300 ml) |
| Matt Black/Black/Cyan/Yellow: PFI-8120 (130 ml)/PFI-8320 (300 ml) |
| Print Head | PF-06 |
| Maintenance Cartridge | MC-31 |
| Scanner | |
Scan Technology | SingleSensor with multiple LED illumination |
| Optical Resolution | 600 dpi |
| Scan Width | 36"/914 mm |
| Minimum Scan Width | 6"/150 mm |
| Maximum Scan Length | 109"/2,768 mm |
| Document Thickness | Min: 0.07 mm |
| Max: 0.8 mm |
| Max. Copy Speed | |
| Draft (300/300 dpi) | Colour: 1 ips/25.4 mm per sec |
| Monochrome: 3 ips/76.2 mm per sec |
| Standard (300/600 dpi) | Colour: 1 ips/25.4 mm per sec |
| Monochrome: 3 ips/76.2 mm per sec |
| Best (600/600 dpi) | Colour: 0.5 ips/12.7 mm per sec |
| Monochrome: 1.5 ips/38.1 mm per sec |
| Max. Scan Speed | |
| Draft (200 dpi) | Colour: 1 ips/25.4 mm per sec |
| Monochrome: 3 ips/76.2 mm per sec |
| Standard (300 dpi) | Colour: 0.5 ips/12.7 mm per sec |
| Monochrome: 1.5 ips/38.1 mm per sec |
| Best (600 dpi) | Colour: 0.33 ips/8.38 mm per sec |
| Monochrome: 1 ips/25.4 mm per sec |
| PC & Software Included | ScanApp Software |
| Functions | Scan to USB: RGB/Greyscale/BW, TIFF |
| (No ScanApp) |
|
| Scan to USB: RGB/Greyscale/BW, JPG, PDF, PDF/A, Multiple PDF (ScanApp available) |
| Scan to Windows PC: RGB/Greyscale/BW, Tiff, JPEG, PDF, PDF/A, TiffG4, Multiple PDF |
| Copy: RGB/Greyscale/BW |
| Copy & Save: Copy and scan to PC concurrently |
