Projection System |
3LCD Technology, RGB liquid crystal shutter |
LCD Panel |
0.59Â inch with C2 Fine |
Color Light Output |
3,700 Lumen- 2,400 Lumen (economy) In accordance with IDMS15.4 |
White Light Output |
3,700 Lumen - 2,400 Lumen (economy) In accordance with ISO 21118:2012 |
Resolution |
WXGA, 1280 x 800, 16:10 |
High Definition |
HD ready |
Aspect Ratio |
16:10 |
Contrast Ratio |
16,000Â : 1 |
Light source |
Lamp |
Lamp |
UHE, 210 W, 6,000 h durability, 12,000 h durability (economy mode) |
Keystone Correction |
Auto vertical: ± 30 °, Manual horizontal ± 30 ° |
2D Vertical Refresh Rate |
100Â Hz - 120Â Hz |
Colour Reproduction |
Upto 1.07 billion colours |
Throw Ratio |
1.30 - 1.56:1 |
Zoom |
Manual, Factor:Â 1.2 |
Lens |
Optical |
Screen Size |
33Â inches - 320Â inches |
Projection Distance Wide/Tele |
1.68 m - 2.02 m ( 60 inch screen) |
Projection Lens F Number |
1.49 - 1.72 |
Projection Lens Focal Length |
16.9Â mm - 20.28Â mm |
Projection Lens Focus |
Manual |
Offset |
10Â : 1 |
USB Display Function |
2 in 1: Image / Mouse |
Interfaces |
USB 2.0 Type A, USB 2.0 Type B, VGA in, HDMI in, Composite in, Cinch audio in, Wireless LAN IEEE 802.11b/g/n (optional) |
Epson iProjection App |
Ad-Hoc / Infrastructure |
Security |
Kensington lock, Security cable hole, Wireless LAN unit lock, Password protection |
3D |
No |
2D Colour Modes |
Dynamic, Cinema, Presentation, sRGB, Blackboard |
Other features |
AV Mute Slide, Auto source search, Built-in speaker, Horizontal and vertical keystone correction, Long lamp life, Quick Corner, Split-Screen-Function |
Video Color Modes |
Blackboard, Cinema, Dynamic, Presentation, sRGB |
Power consumption |
327 Watt, 225 Watt (economy), 0.3 Watt (standby), On mode power consumption as defined in JBMS-84 286 Watt |
Supply Voltage |
ACÂ 100Â V - 240Â V, 50Â Hz - 60Â Hz |
Product dimensions |
302‎ x 237 x 82 mm (Width x Depth x Height) |
Product weight |
2.5Â kg |
Noise Level |
Normal:Â 37Â dB (A) - Economy:Â 28Â dB (A) |
Supported Temperature |
Operation 5° C - 35° C, Storage -10° C - 60° C |
Supported Humidity |
Operation 20% - 80%, Storage 10% - 90% |
|
If the projector is suspended from a ceiling or wall mount and installed in an environment with heavy oil smoke or places where oils or chemicals are volatilized, places where a lot of smoke or bubbles are used for event staging, or where aroma oils are frequently burned, it can make certain parts of our products susceptible to a material degradation which over time could break and cause the projector to drop from the ceiling. |
|
If you are concerned about the environment in which your projector is installed, or if you have any other questions, please contact our support department and they can provide additional assistance. |
Included Software |
iProjection |
Options |
Soft carry case, Wireless LAN unit |
Loudspeaker |
2Â Watt |
What's in the box |
Computer cable, Main unit, Power cable, Quick Start Guide, Remote control incl. batteries, User manual (CD), Warranty card |
Room Type / Application |
Home Office, Home Photo, Streaming, TV & Box sets |
Positioning |
Ceiling Mounted, Desktop |
Colour |
White |
