| Printing Method |
Impact dot matrix |
| Number of Pins |
24 pins |
| Number of columns |
94 columns |
| Pins |
24 Needles (2 x 12) |
| Printing Speed |
HighSpeed-Draft: 480 cpi: 10 chars/s, Draft: 360 cpi: 10 chars/s, LQ: 120 cpi: 10 chars/s, Ultra Speed-Draft: 540 cpi: 10 chars/s |
| Barcodes |
Coda bar (NW-7), Code 128, Code 39, EAN-13, EAN-8, Industrial 2 of 5, Interleaved 2 of 5, Matrix 2 of 5, POSTNET, UPC-A, UPC-E |
| Carbon Copies |
6 plus one original |
| Character Sets |
14 |
| Character Tables |
PCAPTEC, PC437, PC708, PC720, PC850, PC858, PC864, PCAR864, ISO-8859-15, Roman 8, Italic |
| Interfaces |
Bidirectional parallel, RS-232, Hi-Speed USB - compatible with USB 2.0 specification, IEEE 1284 |
| Document Feed |
Single sheet front, Continuous media front, Paper output front and rear |
| Paper Formats |
Sheet Paper (single- and multi-layer), Continuous Paper (single- and multi-layer) |
| Paper Thickness Multi Part |
0.12 mm - 0.53 mm |
| Paper Thickness Single Sheet |
0.065 mm - 0.19 mm |
| Power consumption |
61 Watt, 0.7 Watt (standby) |
| Supply Voltage |
AC 220 V - 240 V, 50 Hz - 60 Hz |
| Product dimensions |
384 x 280 x 203 mm (Width x Depth x Height) |
| Product weight |
7.8 kg |
| Supported Temperature |
Operation 5° C - 38° C |
| Supported Humidity |
Operation 10% - 85% |
| Mean Time Between Failures |
35,000 hours |
| Print Head Life |
400 Million Strokes/Wire |
| Noise |
Operation: 55 dB (A)- Standby: 52 dB (A) |
| Fonts |
Bitmap font EPSON Courier (10 CPI, 12 CPI, 15 CPI), Bitmap font EPSON Draft (10 CPI, 12 CPI, 15 CPI), Bitmap font EPSON OCR-B (10 CPI), Bitmap font EPSON Orator (10 CPI), Bitmap font EPSON Orator-S (10 CPI), Bitmap font EPSON Prestige (10 CPI, 12 CPI), Bitmap font EPSON Roman (10 CPI, 12 CPI, 15 CPI, Proportional), Bitmap font EPSON Sans Serif (10 CPI, 12 CPI, 15 CPI, Proportional), Bitmap font EPSON Script (10 CPI), Bitmap font EPSON Script C (Proportional), Scalable font EPSON Roman T, Scalable font EPSON Sans Serif H |
| Noise Level |
Operation: 55 dB (A) |
