| Printer Type |
5-Colour 24″ (610 mm) |
| Number of Nozzles |
15,360 nozzles (MBK 5,120 nozzles, Other Colours 2,560 nozzles each) |
| Maximum Print Resolution |
2,400 x 1,200 dpi |
| Nozzle Pitch |
1,200 dpi (2 lines) |
| Line Accuracy |
± 0.1% or less |
| Ink Capacity |
Sales Ink: 130 ml / 300 ml (MBK/BK/C/M/Y) |
| Ink Type |
Pigment Ink |
| Printer Language |
SG Raster (Swift Graphic Raster), HP-GL/2, HP RTL, JPEG (Ver. JFIF1.02), CALS G4 |
| Printing Solutions |
Printer Driver (Win/Mac), Direct Print Plus, Free Layout Plus, PosterArtist Windows/Web & Lite, Wi-Fi Connection Assistant, PIXMA Cloud Link, Canon PRINT Inkjet/SELPHY (Mobile), Canon Print System (Mobile), uniFlow server |
| Management Solutions |
Media Configuration Tool (includes Colour Customization Tool), Accounting Manager, Device Management Console, Quick Utility Toolbox |
| Standard Interfaces (Built-in) |
USB B Port: Series B, 4 pins, Hi-Speed USB, Full Speed (12 Mbit/sec), High Speed (480 Mbit/sec), Bulk Transfer Network: IEEE 802.3 10base-T, 100base-TX, 1000base-T, SNMP, HTTP, TCP/IP (IPv4/IPv6), FTP Wireless LAN: IEEE802.11 b/g/n, WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), WPA3-SAE (AES), WPA-EAP (AES), WPA2-EAP (AES), WPA3-EAP (AES) |
| Standard Memory |
2 GB |
| Hard Disk |
– |
| Display |
LCD 4.3 inch / 10.9 cm TFT colour |
| Print Speed |
CAD Drawing (A1 Portrait, Fast Q5): 20 sec Poster (A1 Portrait, Standard): 1 min 23 sec |
| Media Handling |
Roll Paper: One Roll, Top Load, Front Output Cut Sheet: Top Load, Front Output Media Width (Roll/Cut): 203.2 ~ 610 mm Media Thickness: 0.07 ~ 0.8 mm Media Core Size: 2 inch / 3 inch Min. Printable Length: Roll: 203.2 mm, Cut: 279.4 mm Max. Printable Length: Roll: 18 m, Cut: 1,600 mm Maximum Outer Roll Diameter: 150 mm or less Borderless Printing: Supported for roll paper Margins (Recommended / Printable Area): Roll Paper Top/Bottom/Sides: 20 mm/3 mm/3 mm, Cut Sheet Top/Bottom/Sides: 20 mm/20 mm/3 mm; Printable Area Roll: 3/3/3 mm, Cut: 3/20/3 mm |
| Dimensions & Weight |
Main Unit: 978 x 748 x 439 mm Main Unit + Stand + Basket (SD-26): 978 x 885 x 1,060 mm (Basket Open), 982 x 756 x 1,060 mm (Basket Closed) Weight: Main Unit 42 kg, Main + Stand + Basket 55 kg Packaged Dimensions: Printer: 1,152 x 913 x 679 mm; Stand + Basket: 1,058 x 826 x 270 mm; Printer with Stand + Pallet: 1,152 x 913 x 946 mm Packaged Weight: Printer: 73 kg; Stand + Basket: 22 kg; Printer with Stand + Pallet: 96 kg |
| Power & Operating Requirements |
Power Supply: AC 100-240 V, 50-60 Hz Power Consumption: Printing 62 W or less, Sleep 1.6 W or less, Power Off 0.1 W or less Operating Environment: Temp: 15–30 °C, Humidity: 10–80% RH (no dew) |
| Acoustic Sound |
Acoustic Power: Operation approx. 6.2 Bels Acoustic Pressure: Operation approx. 41 dB(A), Standby ≤ 35 dB(A) |
| Accessories |
Printer Stand (SD-26), 2/3″ Roll Holder (RH2-28), Card Reader Interface for uniFLOW (RA-02), Cutter Blade (CT-08) |
| Consumables |
Ink Tank: Magenta PFI-8121 (130/300 ml), Matt Black/Black/Cyan/Yellow PFI-8120 (130/300 ml) Print Head: PF-06 Maintenance Cartridge: MC-31 |
