| Specification |
| Technology |
3LCD Technology, RGB Liquid Crystal Shutter |
| LCD Panel |
0.59-inch with C2 Fine |
| Color Light Output |
3,800 Lumens (Normal) / 2,600 Lumens (Economy) |
| White Light Output |
3,800 Lumens |
| Resolution |
WXGA |
| Aspect Ratio |
16:10 |
| On-Screen Pixel Count |
1,024,000 Pixels |
| Contrast Ratio |
16,000:1 |
| Light Source |
Lamp |
| Lamp Type |
UHE, 210W |
| Lamp Life |
8,000 Hours (Normal) / 17,000 Hours (Economy) |
| Keystone Correction |
Auto Vertical ±30°, Manual Horizontal ±30° |
| Color Video Processing |
10 Bits |
| 2D Vertical Refresh Rate |
100Hz – 120Hz |
| Color Reproduction |
Up to 1.07 Billion Colors |
| Throw Ratio |
1.30 – 1.56:1 |
| Zoom |
Manual, 1.0x – 1.2x |
| Lens Type |
Optical |
| Screen Size |
33″ – 320″ |
| Projection Lens F Number |
1.49 – 1.72 |
| Projection Lens Focal Length |
16.9mm – 20.28mm |
| Offset |
10:01 |
| USB Display Function |
2-in-1 (Image & Sound) |
| USB Ports |
USB 2.0 Type-A, USB 2.0 |
| Video Inputs |
HDMI x2, VGA In x2, Composite In |
| Video Output |
VGA Out |
| Audio Ports |
Audio In x2, Audio Out, Cinch Audio Out |
| Network Connectivity |
Ethernet (100 Base-TX / 10 Base-T) |
| Wireless Connectivity |
Optional Wireless LAN IEEE 802.11a/b/g/n/ac |
| Control Port |
RS-232C |
| Epson iProjection App |
Ad-Hoc / Infrastructure |
| Network Protocol |
PJLink |
| Security Features |
Kensington Lock, Security Cable Hole, Wireless LAN Unit Lock |
| 2D Color Modes |
Dynamic, Cinema, Presentation, sRGB, Blackboard |
| Video Color Modes |
Blackboard, Dynamic, Presentation, sRGB, Theatre |
| Projector Control |
AMX, Crestron, Control4, Extron |
| Special Features |
AV Mute Slide, Auto Keystone Correction, Built-in Speaker, CEC Compatible, Digital Zoom, Direct Power On/Off, Document Camera Compatible, Easy OSD Preset, Network Projection, OSD Copy Function, PC Free, Quick Corner, Split Screen, QR Code Setup |
| Speaker Output |
5W |
| Power Consumption |
286W (Normal), 180W (Eco), 327W (Peak), 225W (Eco Peak), 0.3W (Standby) |
| Power Supply |
AC 100V – 240V, 50Hz – 60Hz |
| Dimensions (W × D × H) |
302 × 249 × 87 mm |
| Weight |
2.7 kg |
| Noise Level |
37 dB (Normal), 28 dB (Economy) |
| Operating Temperature |
5°C – 35°C |
| Storage Temperature |
-10°C – 60°C |
| Operating Humidity |
20% – 80% |
| Storage Humidity |
10% – 90% |
| Included Software |
EasyMP Network Projection, Epson Projector Management |
| Optional Accessories |
Air Filter, Ceiling Mount, Document Camera, External Speaker, Safety Wire Set, Soft Carry Case, Suspension Adapter, ELPWP20 WP System, Wireless LAN Unit, ELPWT01 Wireless Transmitter |
| Installation Options |
Ceiling Mounted, Desktop |
| Color |
White |
