| Specification |
| Printing Technology |
Impact Dot Matrix |
| Print Method |
Bi-directional with logic seeking |
| Control Panel |
4 switches and 5 LEDs |
| Number of Pins in Head |
24 Pins |
| Control Code |
ESC/P2 and IBM PPDS Emulation |
| Print Speed – High Speed Draft |
10 cpi: 347 cps / 12 cpi: 416 cps |
| Print Speed – Draft |
10 cpi: 260 cps / 12 cpi: 312 cps / 15 cpi: 390 cps / (Condensed) 17 cpi: 222 cps / (Condensed) 20 cpi: 260 cps |
| Print Speed – Letter Quality |
10 cpi: 86 cps / 12 cpi: 103 cps / 15 cpi: 129 cps / (Condensed) 17 cpi: 147 cps / (Condensed) 20 cpi: 172 cps |
| Reliability (MTBF) |
Approx. 10,000 POH (25% Duty) |
| Printhead Life |
Approx. 400 million strokes/wire |
| Mean Print Volume Between Failure (MVBF) |
Approx. 20 million lines (Except print head) |
| Character Sets |
Italic table, PC437, PC850, PC860, PC861, PC863, PC865, Abicomp, BRASCII, Roman 8, ISO Latin 1, PC 858, ISO 8859-15 |
| Bitmap Fonts |
Epson Draft (10, 12, 15 cpi), Roman, San Serif, Courier, Prestige, Script, OCR-B, Orator, Orator-S |
| Scalable Fonts |
Epson Roman / San Serif / Roman T / San Serif H (8pt – 32pt, every 2pt) |
| Barcode Support |
EAN-13, EAN-8, Interleaved 2 of 5, UPC-A, UPC-E, Code 39, Code 128, Postnet |
| Paper Path (Manual Insertion / Tractor) |
Rear In, Top Out |
| Paper Media – Cut Sheet (Single) |
L: 100–364 mm / W: 100–257 mm / Thickness: 0.065–0.14 mm |
| Paper Media – Cut Sheet (Multi-part) |
L: 100–364 mm / W: 100–257 mm / Thickness: 0.12–0.32 mm (Total) |
| Envelope (No.6 / No.10) |
No.6: 92 × 165 mm / No.10: 105 × 241 mm / Thickness: 0.16–0.52 mm |
| Continuous Paper (Single / Multi-part) |
L: 101.6–558.8 mm / W: 101.6–254 mm / Thickness: 0.065–0.32 mm (Total) |
| Roll Paper |
Width: 216 mm / Thickness: 0.07–0.09 mm |
| Memory Buffer |
128 KB |
| Supported OS |
Windows 95 / 98 / 2000 / Me / XP / Vista / 7 / 8 / 8.1 / 10 |
| Utilities |
Epson Status Monitor 3, Epson Printer Setting |
| Dimensions (W × D × H) |
362 × 275 × 154 mm |
| Weight |
4.1 kg |
| Consumables |
Ribbon Cartridge Black – C13S015639 (Approx. 2.5 million characters at LQ 10cpi) |
| Options |
Fabric Ribbon Cartridge (Black) – S015634 |
| Operating Conditions |
Temp: 5–35°C / Humidity: 10–80% RH |
| Acoustic Noise |
Approx. 53 dB(A) (ISO 7779 pattern) |
| Interfaces |
Bi-directional Parallel (IEEE-1284 nibble mode), USB 2.0 Full-Speed, Serial |
| Warranty |
02 Years Warranty |
