| Description : |
|
| Display |
Display Size (in.): 20 |
|
Viewable Area (in.): 19.5 |
|
Panel Type: TN Technology |
|
Resolution: 1600 x 900 |
|
Resolution Type: WSXGA (Wide Super XGA) |
|
Static Contrast Ratio: 600:1 (typ) |
|
Dynamic Contrast Ratio: 50M:1 |
|
Light Source: LED |
|
Brightness: 250 cd/m² (typ) |
|
Colors: 16.7M |
|
Color Space Support: 8 bit (6 bit + FRC) |
|
Aspect Ratio: 16:9 |
|
Response Time (Typical GTG): 5ms |
|
Viewing Angles: 90º horizontal, 65º vertical |
|
Backlight Life (Hours): 30000 Hrs (Min) |
|
Curvature: Flat |
|
Refresh Rate (Hz): 60 |
|
Low Blue Light: Software solution |
|
Flicker-Free: Yes |
|
Color Gamut: NTSC: 72% size (Typ) |
|
sRGB: 103% size (Typ) |
|
Pixel Size: 0.27 mm (H) x 0.266 mm (V) |
|
Surface Treatment: Anti-Glare, Hard Coating (3H) |
|
|
| Compatibility |
PC Resolution (max): 1600×900 |
|
Mac® Resolution (max): 1600×900 |
|
PC Operating System: Windows 10/11 certified; macOS tested |
|
Mac® Resolution (min): 1600×900 |
|
|
| Connector |
VGA: 1 |
|
HDMI 1.4: 1 |
|
Power in: DC Socket (Center Positive) |
|
|
| Power |
Eco Mode (Conserve): 11W |
|
Eco Mode (optimized): 14W |
|
Consumption (typical): 17W |
|
Consumption (max): 22W |
|
Voltage: AC 100-240V |
|
Stand-by: 0.3W |
|
Power Supply: External Power Adaptor |
|
|
| Controls |
Physical Controls: Key 1 (favorite), Key 2, Key 3, Key 4, Key 5 (power) |
|
On Screen Display: Input Select, ViewMode, Color Adjust, Manual Image Adjust, Setup Menu |
|
|
| Operating Conditions |
Temperature: 32°F to 104°F (0°C to 40°C) |
|
Humidity (non-condensing): 20% to 90% |
|
|
| Wall Mount |
VESA Compatible: 75 x 75 mm |
|
|
| Input Signal |
Frequency Horizontal: 24 ~ 83KHz |
|
Frequency Vertical: 50 ~ 76Hz |
|
|
| Video Input |
Digital Sync: TMDS – HDMI (v1.4) |
|
Analog Sync: Separate – RGB Analog |
|
|
| Ergonomics |
Tilt (Forward/Back): -4º / 14º |
|
|
| Weight (imperial) |
Net (lbs): 3.5 |
|
Net Without Stand (lbs): 3.1 |
|
Gross (lbs): 5.3 |
|
|
| Weight (metric) |
Net (kg): 1.6 |
|
Net Without Stand (kg): 1.4 |
|
Gross (kg): 2.4 |
|
|
| Dimensions (imperial) (wxhxd) |
Packaging (in.): 20.5 x 13.2 x 3.9 |
|
Physical (in.): 18.24 x 12.93 x 7.66 |
|
Physical Without Stand (in.): 18.24 x 10.6 x 1 |
|
|
| Dimensions (metric) (wxhxd) |
Packaging (mm): 520 x 335 x 100 |
|
Physical (mm): 463.22 x 328.46 x 194.65 |
|
Physical Without Stand (mm): 463.22 x 269.3 x 25.3 |
|
|
| General |
Regulations: RoHS, WEEE, BIS |
|
PACKAGE CONTENTS: VA2025-H x1, HDMI Cable (v1.4; Male-Male) x1, AC/DC Adapter x1, Quick Start Guide x1 |
