| Printing Features |
| Resolution |
203 DPI |
| Printing method |
Thermal Transfer / Direct Thermal |
| Max.print speed |
127 mm/s Max. |
| Max.print width |
104 mm (4.09”) |
| Max.print length |
1778 mm (70″) |
| Media |
| Media type |
Continuous, gap, black mark, fan-fold and punched hole |
| Media width |
25.4~118mm (1.0”~4.6”) |
| Media thickness |
0.06~0.254 mm (2.36~10mil) |
| Media core diameter |
25.4 ~ 76.2 mm (1 “~ 3 “) |
| Label length |
10 ~ 1778 mm(0.39″ ~ 70″ ) |
| Label roll capacity |
127 mm (5“) OD (External diameter) |
| Ribbon capacity |
Max.300m |
| Ribbon width |
110 mm |
| Performance Features |
| Processor |
32-bit CPU |
| Memory |
8MB Flash Memory/8MB SDRAM/Flash memory can be expanded to Max. 4 GB |
| Interface |
Standard:USB TF card Optional: Lan/WIFI/Bluetooth/Serial |
| Sensors |
① Gap sensor |
③ Black mark sensor |
| ② Cover opening sensor |
④ Ribbon sensor |
| Fonts/Graphics/Symbologies |
| Internal fonts |
8 alpha-numeric bitmap fonts, Windows fonts are downloadable from software. |
| 1D barcode |
Code 39, Code 93, Code 128UCC, Code 128 ，subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-8,EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China POST, GS1 DataBar, Code 11 |
| 2D barcode |
PDF-417, Maxicode, DataMatrix, QR code, Aztec |
| Rotation |
0°、90°、180°、270° |
| Emulation |
TSPL、EPL、ZPL、DPL |
| Physical Features |
| Dimension |
282 mm (D) x 232 mm (W) x 171 mm (H) |
| Weight |
2.56kg |
| Reliability |
| Print head life |
30 km |
| Software |
| Driver |
Windows/Linux/Mac |
| SDK |
Windows/Android/iOS |
| Power supply |
| Input |
AC 110~240V,1.8A, 50-60Hz |
| Output |
DC 24V, 2.5A, 60W |
| Options |
| Factory Options |
① WiFi module ② RS-232C(2400-115200 bps) communication interface; ③ Lan ④ Serial |
| Dealer Options |
① External paper roll holder and 1 “paper roll; |
③ Cutter |
| ② Extension board for external paper roll holder |
④ Peeling machine |
| Environmental Conditions |
| Operation environment |
5 ~ 40°C（41~104°F），Humidity: 25 ~ 85% non-condensing |
| Storage environment |
-40 ~ 60°C（-40~140°F），Humidity:10 ~ 90% non-condensing |
